Description Specification Form factor 2.5 inch Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s) Capacities1 480GB, 960GB, 1920GB, 3840GB, 7680GB NAND 3D TLC DRAM Cache Yes Sequential Read/Write 480GB – 560MBs/470MBs 960GB – 560MBs/530MBs 1,920GB – 560MBs/530MBs 3,840GB – 560MBs/530MBs 7680GB – 560MBs/530MBs Steady-state 4k random read/write 480GB – 94,000/41,000 IOPS 960GB – 94,000/65,000 IOPS 1920GB – 94,000/78,000 IOPS 3840GB – 94,000/59,000 IOPS 7680GB – 94,000/34,000 IOPS Quality of service (latency)3,4,5(99.999) Read/Write 480GB – 180/110 uSec 960GB – 3840GB – 200/300 uSec 7680GB – 240/170 uSec Typical latency – read/write <200 µs / <30 us3,4,5 Hot-plug capable Static and dynamic wear levelling Enterprise SMART tools Reliability tracking, usage statistics, life remaining, wear levelling, temperature Hardware-based power loss protection Endurance6 480GB – 876TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 960GB – 1752TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 1920GB – 3504TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 3840GB – 7008TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) 7680GB – 14016TBW, 1 DWPD (5 years), 1.66 DWPD (3 years) Power consumption Idle: 1.30W Average: 1.45W Max read: 1.6W Max write: 3.6W Storage temperature -40℃ ~ 85℃ Operating temperature 0℃ ~ 70℃ Dimensions 69.9mm x 100mm x 7mm Weight 92.34g Vibration operating 2.17G Peak (7–800Hz) Vibration non-operating 20G peak (10–2000Hz) MTBF 2 million hours UBER ≤10 -17 Warranty/support Limited 5-year warranty with free technical support7 SKU: SEDC600M/3840G Categories: Components, SSD, Storage Tags: Components, cpu, electronics, game, gaming, Gaming Custom, gpu, Jordan, motherboard, performa, performapc, store
